Teflon Hose – Corrugated

Applications:
• Provides the utmost in performance, reliability and durability
• Handles rugged conditions, extremes of heat and cold, and corrosive and lethal chemicals
• Teflon is non-aging, has extreme resistance to weather, and its non-stick surface makes cleaning easy

Tube:
• Convoluted Teflon tube with static liner (8500 series) or without (8000 series)

Reinforcement/Cover:
• Stainless steel (304) braid

Temp Range:
• -65°F to +400°F

Request Quote
Email for Quote
Call for Quote
Categories , , ,
Teflon Hose - Corrugated
Teflon Hose - Corrugated - Image 2

Description

Applications:
• Provides the utmost in performance, reliability and durability
• Handles rugged conditions, extremes of heat and cold, and corrosive and lethal chemicals
• Teflon is non-aging, has extreme resistance to weather, and its non-stick surface makes cleaning easy

Tube:
• Convoluted Teflon tube with static liner (8500 series) or without (8000 series)

Reinforcement/Cover:
• Stainless steel (304) braid

Temp Range:
• -65°F to +400°F

Specifications

Part #

I.D

(in.)

O.D

(in.)

Working

PSI

Bend

Radius (in.)

Weight

(lbs/ft)

Standard

Length
With Static Liner

8508

 1/2 0.78 1550 1.5 .23 -
8512 3/4 1.05 1250 2.5 .31 -
8516 1 1.32 1000 3.0 .42 -
8520 1 1/4 1.58 1000 3.5 .52 -
8524 1 1/2 1.83 750 4.5 .59 -
8532 2 2.38 550 6.0 .86 -
Without Static Liner
8008 1/2 0.78 1550 1.5 .23 -
8012 3/4  1.05 1250 2.5 .31 -
8016 1 1.32 1000 3.0 .42 -
8020

1 1/4

 1.58  1000 3.5

.52

 -
8024 1 1/2 1.83 750 4.5 .59 -
8032 2 2.38 550 6.0 .86 -
