Applications:
• Heavy duty suction applications where higher temperature
and abrasion are factors such as vacuum trucks, fly ash,
crushed rock, sand, pea gravel, cement powder
• Lightweight, flexible, extreme resistance to abrasion and
weather
Tube:
• Smooth bore EPDM rubber blended with static carbon
Reinforcement:
• Polyethylene helix embedded with groundable
metal helical wire
Cover:
• Corrugated EPDM rubber
Temp Range:
• -40°F to +220°F
Applications:
• Heavy duty suction applications where higher temperature
and abrasion are factors such as vacuum trucks, fly ash,
crushed rock, sand, pea gravel, cement powder
• Lightweight, flexible, extreme resistance to abrasion and
weather
Tube:
• Smooth bore EPDM rubber blended with static carbon
Reinforcement:
• Polyethylene helix embedded with groundable
metal helical wire
Cover:
• Corrugated EPDM rubber
Temp Range:
• -40°F to +220°F
| Part # |
I.D (in.) |
O.D (in.) |
Working PSI |
Bend Radius (in.) |
Weight (lbs/ft) |
Standard Length |
| 180HR400 |
4 |
4.69 | 30 | 5.5 | 1.75 | 100 |
| 180HR600 | 6 | 6.83 | 30 | 9.8 | 3.46 | 100 |
| 180HR800 | 8 | 9.13 | 30 | 15.0 | 6.00 | 50 |
| Inner Diameter | 4", 6", 8" |
|---|
