Gripper Coupler – Single

A hook-style latching coupling providing a secure seal for installation or removal of low pressure or vacuum tubing lines.

  • Wrap around design, quick connect and disconnect coupling
  • All stainless-steel construction
  • Improved support over rubber hose and band clamps
  • Sizes range from 1-1/2″ O.D. through 12-3/4″ IPS
  • Standard 4″ length for single grippers and 9-1/2″ length for dual grippers
  • Gum rubber or silicone gaskets available

Description

A hook-style latching coupling providing a secure seal for installation or removal of low pressure or vacuum tubing lines.

  • Wrap around design, quick connect and disconnect coupling
  • All stainless-steel construction
  • Improved support over rubber hose and band clamps
  • Sizes range from 1-1/2″ O.D. through 12-3/4″ IPS
  • Standard 4″ length for single grippers and 9-1/2″ length for dual grippers
  • Gum rubber or silicone gaskets available

Specifications

O.D. Size (in.)

Code No. Wt  (lbs.) Part #
1.900 1901 0.65 2401901G2MB
2.000 2001 0.68 2402001G2FGMB
3.000 3001 0.88 2403001G2FGMB
3.250 3251 0.97 2403251G2MB
4.500 4501 1.40 2404501G2FGMB
8.000 8001 2.25 2408001G2FGMB
