GENERAL SERVICE – LIQUID FILLED

Call for price
Category:

Description

The ideal choice for OEM and general industrial applications requiring an economical, liquid filled pressure gauge. When vibration and/or pulsation are present, the glycerin fill liquid dampens the bourdon tube and reduces wear on the movement which extends the life of the gauge. Typical applications include air compressors, hydraulic presses, pumps, cylinders, actuators, and many other types of hydraulic and pneumatic equipment.

Specifications

Part # Size (in.) Internals Case Ring Wetted Parts Window

Pressure

Range

21353G015P25 2 1/2 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 60 PSI
21353G030P25 2 1/2 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 30 PSI
21353G060P25 2 1/2 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 60 PSI
21353G0100P25 2 1/2 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 100 PSI
21353G0160P25 2 1/2 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 160 PSI
21353G05000P25 2 1/2 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 5000 PSI
21353G030P4 4 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 30 PSI
21353G0100P4 4 Brass Stainless Steel Polished Stainless Steel Copper Alloy Polycarbonate 0 - 100 PSI
23353G015P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0  - 15 PSI
23353G030P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 30 PSI
23353G060P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0- 60 PSI
23353G0100P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0- 100 PSI
23353G0160P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 160 PSI
23353G0200P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 200 PSI
23353G0300P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 300 PSI
23353G0400P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 400 PSI
23353G0600P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 600 PSI
23353G03000P25 2 1/2 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 3000 PSI
23353G0300P4 4 Steel Stainless Steel Polished Stainless Steel 316 Stainless Steel Acrylic 0 - 300 PSI
